Technology Articles

2023-02 Connectors Klein Tools, Inc.

[feb 7 2023] Klein Tools cable length meter is a portable time domain reflectometer (TDR) type cable length tester. It can be used to measure cable length, calibrate propagation velocity (VoP) values, determine the distance to cable fault points, and has built-in tone generation for cable tracking. The tester can realize the accurate length measurement of various types of cable at an affordable price. The pac ...

2023-02 Power Pulse Electronics

[feb 7 2023] Pulse Electronics' JX3V Series Pin impregnated Paste (PiP) jack-in Integrated Connector module (ICM) has a 0.9mm pitch that allows solder resistance and flux masks to be deposited or screen printed directly onto the PCB component side in the area directly below PulseJack. The series has 100% electrical and packaging compatibility with the existing JXD2 product line and can be used without recerti ...

2023-02 Power Advanced Energy

[feb 7 2023] The NDQ900 is a fixed-frequency converter with no minimum load requirement. It has active current-sharing capabilities that help connect multiple power supplies in parallel for applications that require greater load current or redundancy capabilities. In addition to PMBus connectivity, the module also provides remote control capabilities and power status signals. Designed with a substrate structu ...

2023-02 Optoelectronics CTS

[feb 7 2023] CIT's miniature VM3S series of sealed process quick switches offer SPST normally open, SPST normally closed and SPDT circuit options. These UL/cUL approved switches are offered in a variety of actuator styles, including pin plungers, standard, short and long hinge rods, rollers, and analog rollers. The VM3S series terminating options include 0.110 "quick connection and 300mm UL 1015 20 AWG wire. ...

2023-02 Semiconductors Infineon Technologies

[feb 6 2023] Infineon Technology has expanded its AC/DC controller ic products by releasing ICC80QSG single-stage PWM controller for flyback topology. The IC is developed for battery charger applications and can provide up to 130W of scalable power design - when optimized with CoolMOS P7 SJ mosfet. It is also an ideal choice for adapter, printer, PC, TV, set-top box, monitor and audio amplifier applications. ...

2023-02 Semiconductors TDK-EPCOS

[feb 6 2023] TDK has introduced the 250W Rated TDK-Lambda RGA Series of rugged non-isolated DC-DC converters. All models carry CE and UKCA marks for low voltage and RoHS instructions and are designed according to IEC/UL/CSA/EN 62368-1 safety standards. Evaluation board is provided to facilitate quick testing. Capable of operating from input voltages of 9V to 40V or 9V to 53V, non-isolated step-down converters ...

2023-02 Power ECS

[feb 6 2023] The ECS extended ECX-2236B series of surface mount crystals includes a higher development frequency, retaining the load capacity and temperature range options of previous versions. In the selected ECX-2236B part number, the customer may order a TR3 part number indicating 3,000 reels instead of the standard 1,000 reels. The ECX-2236B series of ECS comes in an industry-standard 2.5mm x 2.0mm x 0.55 ...

2023-02 Power EPC

[feb 6 2023] ECS 'ECS-3215MV-327KE series HCMOS oscillator comes in a 3.2mm x 1.5mm x 0.9mm ceramic package that provides MultiVolt functionality. These electronic components offer a frequency of 32.768 kHz with ±50 ppm frequency stability and low current consumption of 1.3 µA at standard industrial operating temperatures from -40°C to +85°C. The ECS-3215MV-327KE is a member of the ECS MultiVolt oscillator fa ...

2023-02 Optoelectronics Eaton - Electronics Division

[feb 5 2023] Eaton Electronics button battery supercapacitors are highly reliable, high-power, ultra-capacitive energy storage devices that use electrochemical double-layer capacitor (EDLC) structures and proprietary materials and processes. With this advanced technology combination, Eaton can customize capacitor solutions for backup power, pulse power, and hybrid power system applications. These supercapacit ...

2023-02 Power Alpha Wire

[feb 5 2023] Alps Alps has added two new products to its magnetic sensor product portfolio to support the continuous electrification of cars. These devices are based on the company's record of steering angle detection and electronic gear shifter in the automobile market. With the popularity of driving aids and autonomous vehicle, redundant design is becoming more and more necessary for driving systems. The us ...

2023-02 Power Murata

[feb 5 2023] Murata's Type 2BZ high-performance module is based on Infineon's CYW54590 combo chipset and supports Wi-Fi 802.11a/b/g/n/ac 2x2 MIMO +Bluetooth 5.2 BR/EDR/LE, Data rates of up to 866 Mbps PHY over Wi-Fi and 3 Mbps PHY over Bluetooth. The WLAN part supports the SDIO 3.0 interface, while the Bluetooth part supports the high-speed four-wire UART interface and PCM for audio data. CYW54590 implements ...

2023-02 Semiconductors TDK-Lambda

[feb 5 2023] TDK-Lambda's PYH200 series 200 W DC/DC converters are capable of operating at ultra-wide 12:1 input voltages from 14 V to 160 VDC, and are therefore compatible with 24 V, 48 V, 72 V, or 110 VDC nominal system voltages. Applications include railway rolling stock and trackside equipment, robotics, power generation and scientific research equipment. These converters provide 12 V, 15 V, 24 V, or 48 V ...
