Technology Articles

2023-01 Sensors Bourns

[gen 17 2023] Bourns has announced the addition of 12 new CSM2F series power shunt resistors, extending its product portfolio. The new series uses riveted through-hole metal sensing pins to meet the growing demand for accurate positioning of voltage test points in high-current applications. The latest Bourns CSM2F series of shunt resistor products are designed with Bourns electron beam welding resistor technol ...

2023-01 Power Bridgetek Pte Ltd.

[gen 17 2023] The Bridgetek FT93x series by Bridgetek/FTDI is a compact SuperBridge mcu that provides flexible bridging solutions between different technologies, including USB, UART, SPI and SD host. The unique feature of the USB device port for the MCU is that in addition to supporting all standard classes, the device can simply switch to hard-coded D2xx mode, eliminating the need for a lot of complex USB enc ...

2023-01 Power Wurth Electronics

[gen 17 2023] WCAP-FTBP and WCAP-FTBE from Wurth Elektronik are general purpose DC film capacitors for filtering, blocking, bypass or energy storage. Both series are characterized by high volumetric efficiency and excellent self-healing properties due to the use of metallized film technology. WCAP-FTBP metallized polypropylene DC vessel (MKP) is characterized by excellent voltage resistance, 5% capacitance tol ...

2023-01 Power Diodes Incorporated

[gen 17 2023] Two types of precision power amplifiers (op-amps) with different signal frequencies are produced by Diodes to meet the need of advanced signal regulation in modern automobile design. The low noise ratio characteristics of DIODES AS2376Q indicate that they are optimized for high frequency applications such as on-board chargers (OBCs), DC-DC converters, battery management systems (BMS) implementati ...

2023-01 Sensors Analog Devices

[gen 16 2023] The ADE9153 is a single-phase power metering automatic calibration IC mSure Automatic calibration feature allows meters to automatically calibrate current and voltage channels without using an accurate source or an accurate reference meter when shunt resistance is used as a current sensor. Levels 1 and 2 are automatically calibrated by mSure. The ADE9153 integrates three high-performance analog-t ...

2023-01 Power Maxim Integrated

[gen 16 2023] Maxim Integrated's MAX86150 provides pleurogram (PPG) and electrocardiogram (ECG) measurements via a mobile battery-powered device for health monitoring. The MAX86150 is a biosensor module consisting of an internal light-emitting diode, photodetector, and ECG analog front end (AFE) that delivers highly accurate, FDA-approved PPG and ECG performance in compact power-saving designs that include mob ...

2023-01 Sensors Omron Electronics Inc-EMC Div

[gen 16 2023] Omron's E3AS photoelectric sensor improves part detection, especially when part characteristics change using time of flight (TOF) technology. Traditional triangulation methods are challenged by changing component colors, exotic profiles and varying reflectance. TOF technology detects objects based solely on the distance between them and the sensor, so it is not affected by changes in color or ref ...

2023-01 Sensors TDK

[gen 16 2023] TDK's compact EPCOS E13EMHV series SMT transformers with high dielectric strength. This series of components is widely applicable to various DC-DC converter topologies. The electrical isolation distance complies with IEC 60664-1 and 61558-2-16 standards. The maximum operating voltage is 1000 V DC, and transient overvoltage can be tolerated up to 2500 Vpeak. And the withstand voltage between the p ...

2023-01 Semiconductors TDK InvenSense

[gen 15 2023] TDK InvenSense's SmartBug (MD-42688-P) is a multi-sensor wireless module that utilizes TDK MEMS sensors and algorithms for a wide range of iot applications. This module combines six sensors, a powerful wireless (BLE) MCU, seven algorithm-driven features, and a rechargeable battery all in a small ladybug case. It also offers an add-on board option that includes a Wi-Fi module, an SD card slot, and ...

2023-01 Semiconductors Texas Instruments

[gen 15 2023] The Texas Instruments DAC60502 12-bit DAC is a high-precision, low-power device with a voltage output. The DAC60502 provides linearity of less than 1 LSB. The high accuracy of the tiny package makes the device ideal for applications such as gain and bias calibration, current or voltage set point generation and power supply control. The DAC includes a 2.5V, 5 ppm/°C internal reference that provide ...

2023-01 Sensors Renesas Electronics America

[gen 15 2023] Intersil's ISL8215M power module is a single channel synchronous step-down complete power supply capable of delivering up to 15 a continuous current. Operating from a single 7 V to 42 V wide input power track, the ISL8215M incorporates controllers, power inductors and MOSFEts optimized for space-constrained and battery-powered applications. With high efficiency, including optional light load mode ...

2023-01 Semiconductors Texas Instruments

[gen 15 2023] Texas Instruments' LM76002 and LM76003 regulators are easy to use synchronous step-down DC-DC converters capable of driving up to 2.5 A (LM76002) or 3.5 A (LM76003) load current from inputs up to 60 V. The LM76002 and LM76003 provide superior efficiency and output accuracy at very small solution sizes. Adopt peak current mode control. Other features such as adjustable switching frequency, synchro ...
