TDK introduces EPCOS buffer capacitor retriever
TDK Group has launched EPCOS Buffer Capacitor Finder - an innovative online tool that helps users simplify and speed up the search for suitable buffer capacitors to protect IGBT modules from voltage spikes. With the buffer capacitor finder, users simply enter the manufacturer's IGBT code number at the search mask, and the online tool's integrated database covering the integrated data of more than 1000 IGBT modules from major suppliers automatically assigns the appropriate capacitors.
In addition, users can search by input voltage, capacitance value, capacitor type or terminal configuration. The results of the search include technical drawings of the selected terminals, key technical parameters, and corresponding product specifications. EPCOS buffer capacitors are currently available in 17 different terminal configurations. The corresponding product range ranges from B32656S* to B32686S*. They all have the characteristics of high pulse resistance and stable and reliable terminal contact.
In addition, its components have extremely low ESL values. The terminals are made of tinned copper and the hole spacing ranges from 19.5 mm to 63 mm. These buffer capacitors have voltage ranges from 850 V DC to 2000 V DC, capacitance values from 68 nF to 5.6 µF, and operating temperatures up to +110 °C.
